Decoupling of size and shape fluctuations in heteropolymeric sequences reconciles discrepancies in SAXS vs. FRET measurements.

Fuertes G, Banterle N, Ruff KM, Chowdhury A, Mercadante D, Koehler C, Kachala M, Estrada Girona G, Milles S, Mishra A, Onck PR, Gräter F, Esteban-Martín S, Pappu RV, Svergun DI, Lemke EA, Proc Natl Acad Sci U S A 114(31):E6342-E6351 (2017) Europe PMC

SASDEP2 – Unlabeled Nuclear Localization Signal (NLS) from the inner nuclear membrane protein HEH2 with denaturant

Inner nuclear membrane protein HEH2
MWexperimental 10 kDa
MWexpected 5 kDa
VPorod 10 nm3
log I(s) 8.21×101 8.21×100 8.21×10-1 8.21×10-2
Inner nuclear membrane protein HEH2 small angle scattering data  s, nm-1
ln I(s)
Inner nuclear membrane protein HEH2 Guinier plot ln 8.22×101 Rg: 2.3 nm 0 (2.3 nm)-2 s2
(sRg)2I(s)/I(0)
Inner nuclear membrane protein HEH2 Kratky plot 1.104 0 3 sRg
p(r)
Inner nuclear membrane protein HEH2 pair distance distribution function Rg: 2.3 nm 0 Dmax: 7.1 nm

Data validation


Fits and models


log I(s)
 s, nm-1
Unlabeled Nuclear Localization Signal (NLS) from the inner nuclear membrane protein HEH2 with denaturant Rg histogram Rg, nm
Inner nuclear membrane protein HEH2 OTHER model
Inner nuclear membrane protein HEH2 OTHER model
Inner nuclear membrane protein HEH2 OTHER model
Inner nuclear membrane protein HEH2 OTHER model

Synchrotron SAXS data from solutions of Unlabeled Nuclear Localization Signal (NLS) from the inner nuclear membrane protein HEH2 with denaturant in 25 mM HEPES, 150 mM NaCl, 10 mM DTT, 6 M urea, 0.3 M KCl, pH 7.4 were collected on the EMBL P12 beam line at the PETRA III storage ring (DESY; Hamburg, Germany) using a Pilatus 2M detector at a sample-detector distance of 3 m and at a wavelength of λ = 0.1 nm (I(s) vs s, where s = 4πsinθ/λ, and 2θ is the scattering angle). One solute concentration of 7.50 mg/ml was measured at 23°C. 20 successive 0.050 second frames were collected. The data were normalized to the intensity of the transmitted beam and radially averaged; the scattering of the solvent-blank was subtracted.

The protein contains a penultimate non-canonical amino acid p-acetylphenylalanine (207 Da) that is represented as U (selenocysteine, 168 Da) in the amino acid sequence for the entry. Therefore, the calculated MW from sequence (MW(expected)) must be adjusted accordingly (ca. 40 Da).

Tags: idp
Inner nuclear membrane protein HEH2 (NLS)
Mol. type   Protein
Organism   Saccharomyces cerevisiae
Olig. state   Monomer
Mon. MW   5.4 kDa

UniProt   Q03281 (99-140)
Sequence   FASTA
