Synchrotron SAXS data from solutions of MLL1-WDR5-RBBP5-ASH2L in 25 mM HEPES, 150 mM NaCl, 1 mM TECP, pH 7.4 were collected on the BL19U2 beam line at the Shanghai Synchrotron Radiation Facility (SSRF, Shanghai, China) using a Pilatus 1M detector at a sample-detector distance of 2.4 m and at a wavelength of λ = 0.09184 nm (I(s) vs s, where s = 4πsinθ/λ, and 2θ is the scattering angle). One solute concentration of 2.00 mg/ml was measured at 10°C. 20 successive 1 second frames were collected. The data were normalized to the intensity of the transmitted beam and radially averaged; the scattering of the solvent-blank was subtracted.
s, nm-1
