Synchrotron SAXS
data from solutions of
Mouse High mobility group protein B2 (HMGB2)-dsDNA complex 1:2
in
Tris 50mM, NaCl 150mM, pH 7
were collected
on the
13A beam line
at the Taiwan Photon Source, NSRRC storage ring
(Hsinchu, Taiwan)
using a Eiger X 1M and Eiger X 9M detector
at a sample-detector distance of 2.5 m and
at a wavelength of λ = 0.08265 nm
(I(s) vs s, where s = 4πsinθ/λ, and 2θ is the scattering angle).
One solute concentration of 10.00 mg/ml was measured
at 10°C.
148 successive
2 second frames were collected.
The data were normalized to the intensity of the transmitted beam and radially averaged; the scattering of the solvent-blank was subtracted.
s, nm-1
