| MWexperimental | 203 | kDa |
| MWexpected | 194 | kDa |
| VPorod | 435 | nm3 |
|
log I(s)
6.02×10-2
6.02×10-3
6.02×10-4
6.02×10-5
|
s, nm-1
|
Trypanosome histone variants H3.V and H4.V promote nucleosome plasticity in repressed chromatin
SASDX83 – T. brucei Canonical Nucleosome Core Particle
Histone H2AHistone H2B
Histone H3, putative
Histone H4
Widom 601 145 bp DNA - strand 1
Widom 601 145 bp DNA - strand 2
|
|
|
There are no models related to this curve.
|
Synchrotron SAXS
data from solutions of
T. brucei Canonical Nucleosome Core Particle
in
20 mM HEPES, 150 mM NaCl, 1 mM DTT, pH 7.5
were collected
on the
B21 beam line
at the Diamond Light Source storage ring
(Didcot, UK)
using a Eiger 4M detector
at a sample-detector distance of 3.7 m and
at a wavelength of λ = 0.09464 nm
(I(s) vs s, where s = 4πsinθ/λ, and 2θ is the scattering angle).
In-line size-exclusion chromatography (SEC) SAS was employed. The SEC parameters were as follows: A 50.00 μl sample
at 1.1 mg/ml was injected at a 0.08 ml/min flow rate
onto a GE Superdex 200 Increase 3.2/300 column
at 15°C.
600 successive
3 second frames were collected.
The data were normalized to the intensity of the transmitted beam and radially averaged; the scattering of the solvent-blank was subtracted.
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
