Dmax unknown – experimental data range validation not possible.
There are no models related to this curve.
SAXS
data from solutions of
Calcium/calmodulin-dependent protein kinase type II (CaMKII) subunit holoenzyme with Exon 18 as the linker region + 10 nM Ca2+/CaM
in
50 mM Tris , 0.2 mM CaCl2, 150 mM KCl, 10 mM MgCl2, 2 mM ATP, pH 8
were collected
on the
Rigaku/BioSAXS-2000 SAXS instrument (Institute for Applied Life Sciences/Biophysical Characterization, Amherst, United States)
using a DECTRIS/ PILATUS 100K detector
at a sample-detector distance of 0.4 m and
at a wavelength of λ = 0.154 nm
(I(s) vs s, where s = 4πsinθ/λ, and 2θ is the scattering angle).
One solute concentration of 1.50 mg/ml was measured
at 22°C.
One
600 second frame was collected.
The data were normalized to the intensity of the transmitted beam and radially averaged; the scattering of the solvent-blank was subtracted.
s, nm-1
