Synchrotron SAXS
data from solutions of
Human lung-associated vientovirus FB Replication-Associated Protein ADP-bound (Rep) Hexamer from SEC-SAXS with SVD-EFA analyses
in
20 mM HEPES, 300 mM NaCl, 0.1 mM TCEP, pH 7.5
were collected
on the
ID7A1 BioSAXS / HP-Bio Beamline beam line
at the Cornell High Energy Synchrotron Source (CHESS) storage ring
(Ithaca, NY, USA)
using a Eiger 4M detector
at a sample-detector distance of 1.7 m and
at a wavelength of λ = 1.10367 nm
(I(s) vs s, where s = 4πsinθ/λ, and 2θ is the scattering angle).
In-line size-exclusion chromatography (SEC) SAS was employed. The SEC parameters were as follows: A 100.00 μl sample
at 5 mg/ml was injected at a 0.50 ml/min flow rate
onto a GE Superdex 200 Increase 5/150 column
at 20°C.
500 successive
1 second frames were collected.
The data were normalized to the intensity of the transmitted beam and radially averaged; the scattering of the solvent-blank was subtracted.
s, nm-1
