Synchrotron SAXS data from solutions of Atg17-Atg31-Atg29 Subcomplex in 20 mM Tris, 200 mM NaCl, 2% glycerol, pH 8 were collected on the 12.3.1 (SIBYLS) beam line at the Advanced Light Source (ALS; Berkeley, CA, USA) using a Pilatus3 X 2M detector (I(s) vs s, where s = 4πsin θ/λ and 2θ is the scattering angle). Solute concentrations ranging between 1 and 5.3 mg/ml were measured at 22°C. The data were normalized to the intensity of the transmitted beam and radially averaged; the scattering of the solvent-blank was subtracted and the different curves were scaled for protein concentration.
Wavelength = UNKNOWN. Storage temperature = UNKNOWN. Sample detector distance = UNKNOWN. X-ray Exposure time = UNKNOWN. Number of frames = UNKNOWN
s, nm-1
